1U Single-Channel IoT Server, 460mm Short Chassis, Industrial-Grade Stability, Designed Specifically for 24/7 Operation
Adopts a 4-channel DDR4 memory design for high bandwidth
Features standard tool-less shockproof drive bays, supporting 2 units of 2.5-inch/3.5-inch hard drives
Equipped with an industrial-grade air duct cover for more concentrated airflow and higher cooling efficiency
Industrial-grade wide-temperature tolerance, enabling flexible installation in on-site environments
• Dual Gigabit Ethernet, one full-height PCI-E expansion slot.
• Supports the IPMI 2.0 protocol, enables remote monitoring and management of servers via a web interface, and is compatible with KVM and SOL functions.
| Temperature |
Operating Temperature: -10° to 45°C；Storage Temperature: -40° to 70°C |
| Humidity |
Operating Humidity: 5% to 90% ； Non-Operating Humidity: 5% to 95% |
| PCI-E Expansion Slot |
1 × PCI-E 3.0 x16 (Full-height, Horizontal Orientation) |
| BUTTON |
1× Power ON/OFF， 1× Reset |
| LED |
HHD/LAN1/LAN2 (Active)，Power LED |
| USB2.0 |
2 × Front-mounted USB 2.0 |
| AUDIO |
1 x HD Audio (Line out, Mic-in), Vertical 2-port, 3.5mm |
| IPMI+USB2.0 |
1 × IPMI Management Port + 2 × USB 2.0 |
| USB3.0 |
2 × USB3.0 |
| LAN |
2 × Standard RJ45 (10/100/1000Base-T) Ports |
| VGA + COM |
1 x DB15 + DB9 |
| Network |
1 × RJ45，100/1000Base-T |
| Function |
ASPEED AST2400 BMC ，IPMI 2.0 with virtual media over LAN and KVM-over-LAN support |
| CPU |
Intel® Xeon® processor E5-2600 v3/v4 family |
| Chipset |
Intel® C612 chipset |
| M.2 |
1 × M.2 Interface (2280 NVMe) |
| SATA |
2 × 2.5/3.5-inch SATA Drive Bays |
| Type |
1U, 19-inch chassis, baking finish (matte glossy black) |
| Dimensions |
460mm (D) × 437mm (W) × 44mm (H) |
| Weight |
Approx. 12KG (excluding hard drives) |
| Type |
4 × 4028 Dual-ball Bearing Fans |
| Network Type |
2-Port GbE Network Card |
| Network Controller |
Intel I210-AT |
| Rated Power |
250W |
| Input |
100~240VAC |
| Memory Capacity |
4 × RDIMM Slots, Quad-channel DDR4, Max 512GB |
| Memory Type DIMM Specification |
8GB,16GB,32GB DDR4-2133/2400, RDIMM |
